TP-Link 16-P GBIT POE+ SMART SWITCH

Description

The TP-Link 16-P GBIT POE+ SMART SWITCH is a high-performance solution from TP-Link, designed for professional and commercial applications. This product is built to meet rigorous industry standards, ensuring durability and seamless integration into professional environments.

Key Features:

• FEATURES
• 16 10/100/1000Mbps RJ45 POE+ Ports Switch
• PoE power budget is up to 192W, making it ideal for small to medium business surveillance systems
• Port Priority is able to? guarantee the quality of sensitive application like video monitor
• Intelligent power management can protect the switch from overload
• QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimising traffic for IPTV

Technical Specifications:
FEATURES

? 16 10/100/1000Mbps RJ45 POE+ Ports Switch
? PoE power budget is up to 192W, making it ideal for small to medium business surveillance systems
? Port Priority is able to? guarantee the quality of sensitive application like video monitor
? Intelligent power management can protect the switch from overload
? QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimising traffic for IPTV

SPECIFICATIONS

HARDWARE FEATURES
? Standards and Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
? IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p
? Interface: 16 10/100/1000 Mbps RJ45 Ports
? (Auto Negotiation/Auto MDI/MDIX)
? 2 Gigabit SFP Ports
? Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
? EIA/TIA-568 100? STP (maximum 100m)
? 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
? EIA/TIA-568 100? STP (maximum 100m)
? 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
? EIA/TIA-568 100? STP (maximum 100m)
? 1000BASE-X MMF, SMF
? Fan Quantity: 2 Fans
? Physical Security Lock: Yes
? Power Supply: 100-240V AC, 50/60 Hz
? PoE+ Ports(RJ45): Standard: 802.3at/802.3af compliant
? PoE+ Ports: 16 Ports
? Power Supply: 192W
? Dimensions (W x D x H): 440 ? 180 ? 44mm
? Mounting: Rack Mountable
? Max Power Consumption: 18.73 W (220/50Hz. no PD connected)
? 217.22 W (220/50Hz. with 192W PD connected)
? Max Heat Dissipation63.89 BTU/h (no PD connected)
? 741.15 BTU/h (with 192W PD connected)

PERFORMANCE
? Switching Capacity: 36 Gbps
? Packet Forwarding Rate: 23.8 Mbps
? MAC Address Table: 8K
? Packet Buffer Memory: 4.1 Mbit
? Jumbo Frame: 9 KB

SOFTWARE FEATURES
? Quality of Service: Support Port-based 802.1p/DSCP priority
? Support 4 priority queues
? Rate Limit
? Storm Control
? L2 Features: IGMP Snooping V1/V2/V3
? Static Link Aggregation
? Port Mirroring
? Cable Diagnostics
? Loop Prevention
? VLAN: Support up to 32 VLANs simultaneously (out of 4K VLAN IDs)
? MTU/Port/Tag VLAN
? Management: Web-based GUI
? Easy Smart Configuration Utility
? Transmission Method: Store-And-Forward

OTHERS
? Certification: CE, FCC, RoHS
