LinkQnet CAT5E UTP SOLID NETWORK CABLE – GREEN (SOLD PER METER OR 500M DRUM)

Description

The LinkQnet CAT5E UTP SOLID NETWORK CABLE – GREEN (SOLD PER METER OR 500M DRUM) is a high-performance solution from LinkQnet, designed for professional and commercial applications. This product is built to meet rigorous industry standards, ensuring durability and seamless integration into professional environments.

Key Features:

• FEATURES
• Category 5e Performance – Supports high-speed Ethernet networking for reliable LAN connectivity
• 24AWG Solid Copper Conductors – Ensures stable signal transmission and consistent network performance
• Four Twisted Pair Design – Minimises crosstalk and interference for cleaner data signals
• Standards Compliant – Meets ISO 11801, TIA/EIA 568-C.2 and EN50173 structured cabling standards
• Durable PVC Jacket – Provides protection and flexibility for structured cabling installations

Technical Specifications:
FEATURES

? Category 5e Performance – Supports high-speed Ethernet networking for reliable LAN connectivity
? 24AWG Solid Copper Conductors – Ensures stable signal transmission and consistent network performance
? Four Twisted Pair Design – Minimises crosstalk and interference for cleaner data signals
? Standards Compliant – Meets ISO 11801, TIA/EIA 568-C.2 and EN50173 structured cabling standards
? Durable PVC Jacket – Provides protection and flexibility for structured cabling installations
? Wide Operating Temperature Range – Reliable performance from -20?C to +70?C

SPECIFICATIONS

CONDUCTOR
? 24AWG Solid Bare Copper (0.511mm)

INSULATION
? Polyethylene

PAIR COLOURS
? Blue / White-Blue (0.95mm)
? Green / White-Green (0.95mm)
? Orange / White-Orange (0.91mm)
? Brown / White-Brown (0.91mm)

SHEATH
? PVC
? Nominal OD: 5.2mm

FIRE SAFETY RATING
? IEC 60332-1

TEMPERATURE RANGE
? Installation: 0~50?C
? Operational: -20~70?C

ELECTRICAL CHARACTERISTICS (AT 20?C)
? DC Resistance: 93.8 Ohms/km Max.
? Resistance Unbalance: 2% Max.
? Mutual Capacitance: 56 nF/km Max.
? Capacitance Unbalance: 1000 pF/km Max.
? Skew: 450 ns/km Max.
? Velocity of Propagation: 68% (0.68 ? 3 ? 10? m/s)
? Characteristic Impedance: 100 Ohms ?15% (1~100MHz)
